Trough Mixer

The machine is used to mix inhomogeneous materials evenly. It can used for mixing powder or paste materials. It is horizontal trough type and only has one blade as the mixing blade, so it will be easy to clean the machine.
INQUIRY

trough mixer (4).jpg

XL-C10, C50, C100, C150, C200, C300, C400, C500, C600, C1000 Trough Mixer for Pharmaceutical Industry

Main application:
The machine is used to mix inhomogeneous materials evenly. It can used for mixing powder or paste materials. It is horizontal trough type and only has one blade as the mixing blade, so it will be easy to clean the machine.

Operating principle:
1. The parts contacting the materials are all made of stainless steel.

2. It is horizontal trough type and only has one blade as the mixing blade, so it will be easy to clean the machine.
3. The blade rotates in the trough to mix the different materials. The material trough and the blade rotate reversely and

simultaneously, so that it has a higher efficiency and it can mix more evenly than other general trough mixers.

Main Parameter

Model	XL-C10	XL-C50	XL-C100	XL-C150
Working Volume (L)	10	50	100	150
Spindle Rotation Speed (r/min)	24	24	24	24
Mixing Cycle (min)	5-20	5-20	5-20	5-20
Main Motor Power (kw)	0.25	1.1	2.2	3
Pouring Motor Power (kW)	By Hand	0.75	0.75	0.75
Machine Weight (kg)	40	280	350	410
Overall Size (mm)	600280450	980420800	1100440900	12806001100

Model	XL-C200	XL-C300	XL-C400	XL-C500
Working Volume (L)	200	300	400	500
Spindle Rotation Speed (r/min)	24	24	24	24
Mixing Cycle (min)	5-20	5-20	5-20	5-20
Main Motor Power (kw)	4	5.5	5.5	7.5
Pouring Motor Power (kW)	0.75	1.1	1.1	1.5
Machine Weight (kg)	450	520	580	680
Overall Size (mm)	14006001200	18507001200	21007501250

Model	XL-C600	XL-C1000
Working Volume (L)	600	1000
Spindle Rotation Speed (r/min)	24	24
Mixing Cycle (min)	5-20	5-20
Main Motor Power (kw)	11	11
Pouring Motor Power (kW)	2.2	2.2
Machine Weight (kg)	750	1200
Overall Size (mm)		228011001500
