Ampoule inspection machine

Ampoule optical inspection machine

This machine is an optical inspection equipment for oral liquid ampoules after filling.
INQUIRY

Optical inspection.jpg

Ampoule optical inspection machine

Main application:
This machine is an optical inspection equipment for oral liquid ampoules after filling. When working, the bottles to be inspected are fed into the bottle feeding track by the bottle feeding screw, and then enter the light inspection mouth in turn. There is a white light behind the bottle and 2 in front of the bottle. The magnification is magnified, the foreign matter in the glass bottle is clearly identifiable.

This machine has the advantages of high degree of automation, low labor intensity and easy operation.

Main Parameter:
Production capacity: 80 bottles/min
Applicable bottles: ampoules, vials, oral liquid bottles.
Detection method: visual inspection
Magnification: 2 times
Power source: 220V 50Hz
Work rate: 0.5Kw
Dimensions: 1500×600×1200mm

1. Equipment superiority: simple structure and good effect.

2. Configuration of main components

Gear motor manufacturer: King Vinda Motor

3. Material of main parts
Outsourcing board: 304# stainless steel
Magnifying glass: optical glass

4. Schematic diagram of equipment plan (see attached picture)
