rotary tablet press machine

ZP-5,7,9 rotabry tablet press machine

he machine is a single-press type, continuous automatic tablet press for pressing granular raw materials into tablets. It is sued for small-scale production.
INQUIRY

Product Description

The machine is a single-press type, continuous automatic tablet press for pressing granular raw materials into tablets. It is sued for small-scale production.

Feather:

A. The machine is compliance with the GMP requirement on the production of pharmaceuticals.

B. The compression parts is entirely separated from the driving mechanisms

C. All spare parts to be in contact with the pharmaceuticals are made of stainless steel or the surface being treated specially for non-toxicity & corrosion proof

D. The compression area is enclosed with transparent organic glass. To prevent contaminates, the compression area can be specially treated.

E. All surfaces being smooth & easy to clean.

E. Machine speed, the depth of filling, the thickness of the tablet could be adjusted.

F. The mechanical buffer unit will prevent punches and apparatus from overload damage.

Parameter

Type	ZP-5B	ZP-7B	ZP-9B
Dies	5	7	9
Max.pressure(Kn)	60	60	60
Max.Dia.of Table(mm)	20	20	20
Max.Depth of fill(mm)	15	15	15
Max.Thickness of Table(mm)	6	6	6
Turret speed(r/min)	30	30	30
Production Capacity(pc/h)	9000	12600	16200
Moto(Kw)	2.2	2.2	2.2
Overall size(mm)	4804901100	4804901100	4804901100
Net weight(Kg)	260	260	260
